Description
Fitment: Internal balance. Replaces 28oz. external balance in custom builds. 4 bolt standard Ford pulley bolt pattern. Pulley space #717656 may be required on some 1975-later engines. Custom pulleys may be required on 1969 & earlier engines.
| PART # |
650231 |
| Fitment |
Ford 302/351. Internal balance. Replaces 28oz. external balance in custom builds. 4 bolt standard Ford pulley bolt pattern. Pulley space #717656 may be required on some 1975-later engines. Custom pulleys may be required on 1969 & earlier engines. |
| Bore Diameter |
1.3745″ |
| Degree Marking Range |
2 degree increments, 50 BTDC to 10 ATDC |
| Degree Markings |
Engraved |
| Engine Balance |
Internal |
| Finish |
Black Zinc |
| Keyway |
Single; (3/16″) |
| Length |
3.500″ |
| Material |
Steel |
| Mounting Hardware Included |
No |
| Outside Diameter |
6-5/8″ |
| Pulley Bolt Pattern |
4 bolt standard Ford pulley pattern. Pulley spacer (Fluidampr #717656) may be required on some 1975-later engines. Custom pulleys may be required on some 1969-earlier engines. |
| Safety Rating |
SFI 18.1 |
| Weight / Rotating Weight |
11.1 lbs / 7.4 lbs |
Shipped Australia-Wide
- Dispatched from within Australia with tracking.
- Same-day dispatch on in-stock orders placed before 11am AEST, Monday–Friday.
- Shipping is calculated at checkout based on size, weight and your delivery address.
- Estimated delivery 2–7 business days depending on your location.
Freight question? Call us on (07) 5619 7869.
PART # 650231 Fitment Ford 302/351. Internal balance. Replaces 28oz. external balance in custom builds. 4 bolt standard Ford pulley bolt pattern. Pulley space #717656 may be required on some 1975-later engines. Custom pulleys may be required on 1969 & earlier engines.
